GESTER Toys safety tester meet with standards ISO 8124, EN 71, ASTM F963,16 CFR 1500 and test for shape, size, contour, spacing as well as acceptable criteria for properties peculiar to certain categories of toy.
Baby Stroller Testing Machine Rotating Test GT-MH22 Product Introduction Application: The tester can attach the vehicle by its wheels or axles to the rigid platform which can be orientated in an axis parallel to the ground. Slowly rotate the vehicle with the test mass through a specified angle to the horizontal both in a clockwise and anticlockwise direction such that the attachment devices alone transmit the test load to the chassis or seat unit , and maintain this position for an specified time in each direction. Satndards: EN 1888-2012 Section8.1.3.2.1 ,8.10.2, GB 14748-2006 Section 5.15 Feature 1.The test platform with wheel axle fixing device. 2.The test platform can rotate clockwise and counter clockwise. 3.Automatic judgment of specimen damage, automatic stop working. 4.Programmable control rotation angle, test frequency, cycle test, spacing interval 5.Can autosave when interruption of power supply, can choose to stop or continue to work 6.High precision angle sensor, can display table angle in real time. Key Specifications Rotating speed 4±0.5rpm Control mode PLC Display mode 7 inch screen touch screen display Date display Angle, frequency Power supply AC 220V, 50Hz
EN 14988 High Chair Comprehensive Testing Equipment GT-MJ01 Product Introduction Application: This tester is used for testing the mechanical properties of high chair. Can perform the horizontal static load and vertical static load and static load on backrest. The High Chair Comprehensive Testing Equipment is equipped with two drive units, and can be individually controlled to repeatedly load the test points . Through different parameter settings, the machine can complete the following types of test functions on the high chair: 1. Seat,tray and back and footrest static load test. 2. Horizontal outward static loading test for front part of the high chair 3. Strength components of the restraint system and belt attachment point test 4. High chair stability test Standards: EN 14988-2017 Section 8.8.6.2, 8.8.6.3, 8.9.3.2.2, 8.11.2.2, 8.12.2.3, 8.12.2.4, 8.12.2.5, 8.12.2.6 Feature 1. The main structure of the machine is made of aluminum, beautiful and easy to maintain. 2. Servo motor drive, test loading control is more accurate, and the noise is even smaller. 3. High Chair Comprehensive Testing Equipment PLC touch screen control makes the operation more convenient. 4. In addition, the machine loading device using electric control movements, more extensive test space. Key Specification Model GT-MJ01 Vertical load capacity 1000N Horizontal load capacity 1000N Testing time 0-99999 (can be adjustment) Control method PLC touch screen control Lifting Method Automatic lifting Power 1 phase AC 220V 50/60Hz Dimension (W×D×H) 180×250×200cm Weight 900kg Accessories: Standard Accessories 2pcs GT-LB01-5 local loading pad 4pcs Stops 2pcs Stationary fixture Optional Accessories 1pc GT-MJ23-1 test beam 1pc GT-MJ27 test loading
This Stroller Handle Tester is suitable for baby trolley simulation over the barrier when the lifting and under the action of the durability test, the test method is to place the baby model in the car, raised when the car back to the ground 120±10mm, under pressure When the front wheel to the ground 120±10mm, 15±2 times per minute, and continue to test the number of times after the test, the visual car with or without damage.
High Chair Seating Impact Testing Equipment GT-MJ31 Product Introduction Application: This tester applies to all types of high chairs, with 2 functions of chair seating impact and seating durability test. The purpose of this test is to evaluate the ability of the chair to withstand heavy and abusive impact forces on the seat and evaluate the ability of chairs to withstand fatigue stresses and wear caused by downward vertical force(s) on the seat. Standards: EN14988-2017 Section 5.17, 8.8.5 Feature 1.The main structure of the machine is made of aluminum, beautiful and easy to maintain. 2. Using PLC touch screen control, operation more convenient. 3. In addition, the machine loading device using electric control movements, more extensive test space. Key Specification Model GT-MJ31 Impactor Diameter 150mm Impactor Weight 23kg Cylinder Stroke 0~300mm Beam Stroke 900~1350mm Test Speed 10~30r/min Test Times 0~999999times, settable Control PLC touch screen control Dimensions(W×D×H) 150×150×200cm Weight ≈300Kg Air Source ≧7kgf/cm^2 stable air source Power 1∮ AC 220V 50Hz 5A Accessories: 23kg Impactor 1pc
Toys Scooter Steering Tubes Strength Tester apply to test the strength of toy scooter steering tubes,including resistance to downward forces and resistance to upward forces.
Needle Flame Tester is the latest release of the flaming test equipment, with imports of touch-screen controller and instrument. Apply to the test standards IEC60695,GB5169, etc.
Hot Wire Ignition Tester GT-MC38 Product Introduction Standards: IEC60950, GB4943, IEC 60477-1 clause 5.2.5.4 Feature Programmable control system Precision adjustable power supply Imported aluminum fixture Equipped with test ventilation device One-button timing device Advanced power control system Multiple safety protection system Tempered glass window Key Specification Model GT-MC38 Internal dimensions 1120mm*600mm*1020mm (W*D*H) Internal volume ≥0.5m³ Controller 7-inch programmable controller Hot wire material Nickel-Chromium wire (Nickel 80%, Chromium 20%) Hot wire length 250mm Hot wire diameter 0.5mm Hot wire cold resistance 5.28Ω Hot wire power 0.26W/mm±4% Test time 0.01-999.99S can be set Ignite time 0.01-999.99S Stop burning time 0.01-999.99S Accessories Standard Accessories 1 pc Hot wire 1 pc Fixture 1.5metres Current line 2.5metres Exhaust pipe
