Mask Tightness Tester GT-RA12-3

The mask tightness tester can quickly complete the tightness test of respirators such as masks to ensure that it provides good protective performance.
  • Brand:

    GESTER
  • Item NO.:

    GT-RA12-3
  • Order(MOQ):

    1
  • Product Detail

Mask Tightness Tester GT-RA12-3



Product Introduction

Application:

In order to prevent infection at the medical site and during labor work, workers must be protected from inhalable hazardous substances in the workplace, and respirators such as masks must be worn during work. Select a respirator, such as a mask, based on your facial features, and evaluate the tightness between the respirator, such as a mask and the face, to check whether there are gaps or leaks that put workers at risk. The mask tightness tester can quickly complete the tightness test of respirators such as masks to ensure that it provides good protective performance. Security experts will also develop protection schemes and standard regulations based on the results of the tightness test. Widely used in hospitals, manufacturing plants, production sites, fire-fighting workplaces and other official testing agencies.



Standards:

GB 19083-2010 Technical Requirements for Medical Protective Masks

GB2626-2019 Respiratory protection—Non-powered air-purifying particle respirator


Features:

  1. Quantitative tightness test for respirators such as masks (QNFT)
  2. Applicable to 100/99 / P3 / HEPA series mask disposable filter mask tightness test (including
  3. N95 / N90 / KN95 and other disposable dust masks)
  4. Adhesion test of half mask and full face mask
  5. Gas mask tightness test
  6. PAPR mask tightness test
  7. SCBA respirator mask tightness test
  8. 7inch true color touch screen
  9. Independent or computer controlled
  10. Using CNC technology
  11. English, French, Spanish, Portuguese, Chinese language switching display
  12. Complies with US OSHA standards, Canadian Standards Association (CSA) guidelines, including N95
  13. Equipped with a variety of communication interfaces (USB, Ethernet), and can also enable WIFI

Instrument characteristics

How to choose a high-quality mask not only depends on the filtering efficiency of the mask, but also to confirm whether the mask is completely in contact with the face, otherwise aerosol particles such as germs that have not been filtered by the mask will be inhaled from the inadequate adhesion.


Therefore, it is very important to check the wearing status of the mask. The European and American countries have listed the application test of the mask as a strong inspection item.


For example, the N95 mask is one of 9 types of particulate protective masks certified by NIOSH (National Institute of Occupational Safety and Health). "N" indicates oil resistance. "95" indicates that the particle concentration in the mask is more than 95% lower than that of the particles outside the mask when exposed to the specified number of special test particles. N95 is not a specific product name, as long as it meets the N95 standard and passes the NIOSH review, it can be called "N95 mask".


N95 type masks, in addition to the filtering efficiency of the masks, the closeness of the masks to the face is one of the important factors that determine the effectiveness of the use of the masks. The suitability of different types of masks for the human face varies greatly. Therefore, before using a mask, the suitability of the mask should be checked first. During the tightness test of the wearer's face, ensure that air can pass in and out through the mask when it is close to the edge of the face.

The mask tightness tester can quickly complete the tightness test of respirators such as masks to ensure that it provides good protection performance.


Our mask tightness tester uses CNC technology, suitable for 100/99 / P3 / HEPA series masks disposable filter mask tightness test (including disposable dust masks such as N95 / N90 / KN95), gas masks / breathing masks, Adhesiveness test of half-mask and full-face mask, independent or computer control, five languages switch display, equipped with multiple communication interfaces (USB, Ethernet), WIFI can also be enabled, one computer can control four instruments at the same time.


Key Specification



Model

GT-RA12-3

Concentration range

0 ~ 100,000 / cm3

Grain diameter

0.02 ~ 1.0μm

Flow

Sampling flow: 100cm3 / min Total flow: 700cm3 / min

Closeness coefficient test

direct test (Cout / Cin)

Liquor

99.5% + isopropanol (analytical grade)

Display

7inch true color touch screen

Communication interface

USB × 3 (Host × 2, Device × 1) Ethernet interface × 1

Connection port

environment port, sampling port

WIFI

equipped

Languages

English, French, Spanish, Portuguese, Chinese

Flow control

sensor control

PC controllable operation

one computer can control 4 instruments at the same time

Data output format

Microsoft Excel

Working temperature

15 ~ 35 ℃

Power supply

AC 110 ~ 240V 50 / 60Hz

Appearance size

208×117×262mm

Weight

2.1kg

Accessories:

Standard Accessories

Alcohol reagent bottle

Protective cap

Reagent stick

Zero-count filter

Strainer

Sampling tube

Instruction manual

AC adapter

Touch screen pen

Optional accessories

Computer

Test kit for tightness coefficient
