EN 14988 High Chair Comprehensive Testing Equipment GT-MJ01 Product Introduction Application: This tester is used for testing the mechanical properties of high chair. Can perform the horizontal static load and vertical static load and static load on backrest. The High Chair Comprehensive Testing Equipment is equipped with two drive units, and can be individually controlled to repeatedly load the test points . Through different parameter settings, the machine can complete the following types of test functions on the high chair: 1. Seat,tray and back and footrest static load test. 2. Horizontal outward static loading test for front part of the high chair 3. Strength components of the restraint system and belt attachment point test 4. High chair stability test Standards: EN 14988-2017 Section 8.8.6.2, 8.8.6.3, 8.9.3.2.2, 8.11.2.2, 8.12.2.3, 8.12.2.4, 8.12.2.5, 8.12.2.6 Feature 1. The main structure of the machine is made of aluminum, beautiful and easy to maintain. 2. Servo motor drive, test loading control is more accurate, and the noise is even smaller. 3. High Chair Comprehensive Testing Equipment PLC touch screen control makes the operation more convenient. 4. In addition, the machine loading device using electric control movements, more extensive test space. Key Specification Model GT-MJ01 Vertical load capacity 1000N Horizontal load capacity 1000N Testing time 0-99999 (can be adjustment) Control method PLC touch screen control Lifting Method Automatic lifting Power 1 phase AC 220V 50/60Hz Dimension (W×D×H) 180×250×200cm Weight 900kg Accessories: Standard Accessories 2pcs GT-LB01-5 local loading pad 4pcs Stops 2pcs Stationary fixture Optional Accessories 1pc GT-MJ23-1 test beam 1pc GT-MJ27 test loading
The Manual Rotary Vertical Crockmeter is used to determine the amount of color transferred from the surface of colored textile materials to other surfaces by rubbing.
