Brand:
GESTERItem NO.:
GT-UA01-3TOrder(MOQ):
1Payment:
T/T, L/CLead Time:
15-30 daysProduct Detail
30KN Dual Column Universal Testing Machine GT-UA01-3T
Application:
This universal testing machine is designed for conduct tensile, compression, bending, shearing, bonding strength, peeling, tearing and other tests for rubber, plastic, leather, metal, nylon line, fabric, paper, aviation, packaging, construction, petrifaction, electrician, vehicle and other materials. It is a basic equipment of quality control, receiving inspection, physical test, mechanics research, material development.
Standards:
SATRA TM5, TM53, TM52, TM51, TM108, TM113, TM117, TM118, TM120, TM123, TM149, TM162, TM401, TM 411, TM 410,
ASTMD 751/ 2209 /412 / 624 /638 / 790, FIA 1206,
BS5131- 3.7, 5.11, 5.13 , BS 5153-2.6
ISO22650, ISO 19958, ISO 3377-1, ISO 3377-2, ISO 11644, ISO 20866, ISO 20867, ISO19957, ISO20874, ISO20344-5.2.4, ISO 20345-5.3.1.2, ISO17698, ISO20875, ISO22777, ISO22776, ISO22654, ISO20863, ISO20876, ISO17695, ISO17697, ISO34-1, ISO36, ISO37, ISO 17708, ISO 17696, ISO17706,
AS/NZS 2210.2-5.2.4
DIN 53331
GB/T 3903.8, GB/T 3903.9, GB/T3903.14 ,GB/T3903.20, GB/T3903.21, GB/T3903.22, GB/T 3903.23 , GB/T 3903.24, GB/T 3903.25, GB/T 3903.26, GB/T 3903.29, GB/T3903.32, GB/T 3903.39,
GB/T 3903.40, GB/T 3903.43, GB/T 4689.20, GB/T20991-5.2.4, GB 21148-5.3.1.2, GB/T 17928,
GB/T529, GB/T528, GB/T532, GB/T21396
QB/T 11413, QB/T 2711, QB/T2675, QB/T2883, QB/T4118, QB/T4198
HG/T 2726, HG/T 2877, HG/T4805
The power system: servo motor and servo drivers and worm gear and rod reducer and ball screw.
Control system: adopting Pulse Command control method, it will be more accuracy and easy to control.
The speed control range: 0.001-500mm
The intermediate plate adjustment is both fast coarse and slow fine-tuning.
it will return to original site and save automatically after testing.
Data transmission mode: RS232 transmission.
This universal tensile test machine can realize constant speed, positioning, constant power, constant stroke control mode and multi-level control mode which can meet the test requirements of the ordinary.
Testing space: test width is 400 mm (standard)
All plate walking space: 1100 mm (excluding fixture, according to the customer requirements).
The entire displacement: the encoder is 1800 P/R, it can improve 4 times accuracy
This tensile testing equipments using the LINE DRIVE encoder strong anti-interference ability displacement resolution 0.001 mm.
Safety device: overload emergency stop device, up and down stroke limit device, leakage automatic blackout system, automatic break point stop function.
Model
GT-UA01-3T
Max. Capacity
30KN
Control Mode
Computer control
Force Resolution
1/100,000
Force Accuracy
≤+/-0.5%
Stroke Resolution
0.001 mm
Extensometer Resolution
0.001 mm
Test Speed
0.001-500mm/min
Walking space
1100mm (it can be custom-tailor according to their requirements)
Force Unit Switch
Kgf, N, Ibf, g, ton, Mpa
Stop Mode
Overload stop, emergency stop button, specimen damage automatic stop, upper & lower limit set automatic stop, automatic reset function
Machine Drive
Servo motor drive, synchronous wheel and precision ball screw drive
Power Supply
AC 220V 50/60HZ
Dimensions
About 110cm x 70cm x 240cm(WxDxH)
Weight
About 400kg
Accessories:
Standard accessories |
1pc |
English operation software |
1pc |
Cable connect with PC |
|
Option accessories |
Optional |
Desk Top Computer |
Optional |
Other grips |
|
Optional |
Extensometer |
